Skinner, Frank W. (Frank Woodward), 1858-1932 · New York, McGraw · leaf 202
ST FIXED SHOES 185 and locks them against lateral displacement. The pin nuts arechambered, and engage bosses cast on the shoe and pedestalwebs. Omalia. — The fixed ends of the double-track 61-ft. plategirders of the Missouri River bridge of the Omaha Bridge &Terminal Railway Company at East… … <mr~-i Turned Bolfs. Fixed End Bearing for Skew Deck Spans.Omaha Bridge. have three longitudinal and three transverse webs, and the 7-in.pin engages full holes in the outside webs, which clear eachother so as to be locked together like pairs of jaws. The pincenter is 12 in. below the bottom of…
Bridges
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
