63 made by riveting bed plates, a web plate and stiffener angles tothe bottom flange of the girder, so as to have the effect ofextending the girder web below the lower flange and making itact as a longitudinal kneebrace with inclined flange stiffeningangles. Bridesburg Approach.—The approaches of… … Support of Longitudinal Girders, Details of Girder Connections. Bridesburg, Philadelphia, are double-track steel viaducts of about3450 ft. total length. The regular spans have four lines of40-ft. plate girders supported on the tops of the trestle columnsand on transverse girders web-connected to…
