Skinner, Frank W. (Frank Woodward), 1858-1932 · New York, McGraw · leaf 345
e and thin plates connected to theweb with a single row of |-in. rivets ; the top flanges are efficientcompression members, and the deep thin web is stiffened by widetransverse diaphragms, which, with their double flange angles,provide thorough connections between the top and bottomflanges. The web… … O ^-\^ y////^^^^^^^^^^^^^^- LONG HIGHWAY SPANS 329 side, with a single row of rivets in each edge of each web plate.The web is divided by its vertical stiffeners into two 6-ft. endpanels and 20 intermediate panels a little more than 10 ft. long,each of the latter being composed of five plates, as…
Bridges
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
