ur rows : the bottom flange is spliced with a pairof cover angles and a cover plate, having altogether two rows ofrivets in the sides, and four through the flange. At the deepestpart of the girder, where it is supported by the vertical posts,the web is reinforced by side plates and angles, and is… … Transverse Bents. girder. The column channels extend to the top flange of thegirder, which passes between them, and is field-riveted to themthrough the diaphragm flanges. The joint betwieen the columnand the inclined lower flanges of the girder is covered with bentplates shop-riveted to the girder…
