plates and the bent ends ofthe vertical web stiffeners of the girderwhich are connected to it, as shown inthe detail. The shoe has half-hole bear-ings on a 7-in. pin in the top of a ped-estal with a 4 X 45-ft. base, which is seated on a nest of twelve 4-in. rollers secured by the ordinarytop and… … CANTILEVER SPANS 353 Stresses through rivets in the girder web. The rods are about30 ft. long, and their lower ends pass between the webs of a pairof 20-in. I-beams, and their nuts engage bearing plates on the
