Skinner, Frank W. (Frank Woodward), 1858-1932 · New York, McGraw · leaf 384
5ide View a+ Arch BraceSuspension of Continuous Spans. EXAMPLES OF PLATE GIRDER CONSTRUCTION ^,6? … 368 BRIDGE CONSTRUCTION flanges, by plate girder floorbeams 2 ft. deep and about 10^ ft.apart. These carry three lines of web-connected 9-in. I-beamstringers, between which there are asphalted 8-in. red brickarches of 5f-ft. span. On a concrete filling above the arches isa pavement of vitrified…
Bridges
