Skinner, Frank W. (Frank Woodward), 1858-1932 · New York, McGraw · leaf 73
he girders are web-connected to the end floorbeams ofthe channel span. At the shore end they are seated on bedplates bolted to the abutment masonry. At this end there is a^-in. sole plate countersunk-riveted to the lower flange with a4^ X I-in. notch in the center of each longitudinal edge toclear… … Hole for l^ Anchor Bolt <rBolf^
