1^ ^QOO BtoB ofLS Center Girder. … Details of Heavy Girder. — Forest Park Bridge. plate. The web is | in. thick throughout, and has fourjoints spliced with two pairs of top and bottom horizontal12 X f-in. plates clearing the flange angles, and one pair of14 X l-in. vertical plates clearing the horizontal plates.Besides these the…
