Types and details of bridge construction (1904)
Skinner, Frank W. (Frank Woodward), 1858-1932 · New York, McGraw · leaf 91
ntersunk-rivetedto the ends of their lower flanges, and projecting some distancebeyond the edges of the latter. (Seepage 126.) The webplates are 10 ft. deep, planed on all edges, and vary from i in.thick and 9 ft. 2^^ in. long at the ends to i in. thick and13 ft. 7-j^g in. long at the center. They… … End Elevation. Sid© Elevation. Cross- Section, Center Girder. Oriskany Bridge. 15 X I in. middle splice plates have only four rows of rivets. Ateach splice and midway between them there is a pair of 6 x 4 X ^in. vertical web-stiffener angles with fillers all machined to endbearings. The top and…Bridges
