The useful arts and manufactures of Great Britain (1861)
Tomlinson, Charles, 1808-1897, Society for Promoting Christian Knowledge (Great Britain). Committee of General Literature and Education · London : Society for Promoting Christian Knowledge · leaf 568
o tlie hollow gudgeon is fixed a pinion a, into which a toothed wheel h works ; this wheel is fixed on a short spindle s, supported on proper bearings ; at the other end of this short spindle is a bevel pinion c, which works another bevelled wheel d, attached to the spindle that carries one of the… … Now, it will be evident, that as the whole frame revolves, these pulleys are set in motion also; the revolution of the frame imparting twist to the strand, and the motion of the pulleys dragging it forward through the register tube. The same motion which effects these operations is also made…
Textile printing · Textile industry · Textile fabrics
Internet Archive · NCSU Libraries · Public domain (published before 1931). Free to use for anything.
