The valve-setter's guide; a treatise on the construction and adjustment of the principal valve gearings used on American locomotive (1910)

Kennedy, James, 1848-1922 · New York, A. Sinclair company · leaf 57

An illustration from The valve-setter's guide; a treatise on the construction and adjustment of the principal valve gearings used on American locomotive, 1910, leaf 57 — extent equal tothe amount of its vibration at the pointA; the center F is for this purpose car- crum, F, of the lever, E, is represented inFig. i. The shaft, L, and the links canbe partially rotated on the center of theformer, so that the slots in the links willbe inclined over to either side of a… … FIG. i. ELEVATION OF JOYS VALVE GEAR. ried vertically in blocks which slide inslots in the links JK, which are curved toa radius equal to the length of the rod G,connecting the lever F to the valvespindle. These links are attached to ashaft, L, Figs. 2 and 3, corresponding tothe ordinary lifting…

Locomotives
