Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 120
110 VALVE SETTING strokes. This may be demonstrated by marking both crosshead and guideat cut-off on the forward stroke, and making a second cut-off mark on theguide the same distance from the dead center on the return stroke. Whenthe crosshead reaches this second mark, on the return stroke, the…
Steam-engines
