Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 131
ulting withthe builders. Practical Illustration of Setting Valves i\-n illustration of valve setting on this type of engine is given inthe following experience. On indicating the engine a friction-load dia-gram such as is shown in Fig. 118 was taken. The head-end diagramshowed some 30 lbs. less… … J^IG. 122. the nut J, Fig. 115. This had the effect of more lap on the head-endsteam valve and less on the crank end, giving the diagram in Fig. 119,where the initial pressures were broiight within 8 lbs. of each other by the change. It will be noted that thehead end had the latest cut-off by the…
Steam-engines
