nsure vertical motion of the valve, E F H \s the lever,having its fulcrum at E and loaded at //with the weightG, which is raised by the pressure on the valve at F. A later form of valve, shown by A, Fig. 675, is a turnedcyhnder moving vertically between four guides B, B, andattached by the bolt C…
