Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 138
ut-off desired by giving the eccentric a greaterthrow and consequently the valve more travel. The above applies to the cross-compound engines as well as tandemengines, with the exception that, when setting the eccentric on the low-pressure cylinder in a cross-compound, the eccentric must be set… … Crank Pin ^^^B Cyl. End FIG. 131. advisable to so adjust the cut-off in the low-pressure cylinder, and conse-quently the receiver pressure, that the load will be evenly divided betweenthe high- and low-pressure cylinders for rated load conditions. For verylight loads the high-pressure cylinder will…
Steam-engines
