e hub ofthe governor wheel; the eccentric isthus compelled to move with theweight arm and its position variesas the stud moves nearer or fartheraway from the shaft center, due toinertia and centrifugal force. Thedisk D, Fig. 145, is the oil guardand has nothing to do with theaction of the… … FIG. 142. — AN EASY METHOD OF PUT-TING THE ENGINE ON CENTER. To Set the High-pressuee Valve To set the high-pressure valve the valve plug V, Fig. 146, and the coverat D must be removed. With the piston valve enveloped by its bushing,it is impossible to see the valve itself, except at the top, and…
