Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 156
redesigned. sions only, therefore the valves are set in the same manner for all, themeasurements differing of courseand important measurements. The above table gives further details XV THE EICE AND SAEGENT ENGINE This engine, as shown by the cut given herewith, is of the heavy-dutyCorHss type,… … FIG. 149. made as short as advisable, and all parts made very strong with unusuallylarge wearing surfaces. The illustration (Fig. 149) represents a small,simple engine. The company also builds compound engines of both tan-dem and cross types and vertical engines of large sizes; the sizes…
Steam-engines
