Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 98
convey the gases to and from the inlet and exhaust valves re-spectively. The inlet valve, and the inlet valve spring are held in one unitby a removable metal housing known as a Valve Cage, whichis arranged so that the cage, valve, and spring may be re-moved as one piece from the cylinder casting… … Fig. 18. Elevation of Muenzel Engine Showing Lay Shaft and Valve Connections. left by the removal of the inlet valve cage. Both valves aresurrounded by a water jacket, as are the passages that lead tothem. Both the inlet and exhaust valves are opened and closed atthe proper moments in the stroke by…
Internal combustion engines · Traction-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
