Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 174

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 174 — i is a bracket which helps support the rockshaft fc. Fig. 168 illustrates the exhaust wrist plate F, which is on the sameshaft, only at the end opposite to that occupied by the steam wrist plate.It will be noted that the valve-rod pins in the wrist plate are set abovethe center of the plate, while… … FIG. 167. Both the steam and exhaust valves are lapped when they are down atthe lower end of their travel, with the plunger in the dash pot seated. 164 VALVE SETTING When traveling up the valves open, and close in coming down, but to geta complete understanding of the movement of each valve,…

Steam-engines
