Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 178
llthen be ready to travel in the direc-tion of the arrow when the gov-ernor takes hold. When the valve gear is in the position shown in Figs.169, 170, 171, and 172 the rod S and plate d are as shown in Fig. 174. With conditions as in Fig. 174, the valve is given its full maximumtravel, but from… … FIG. 173. 168 VALVE SETTING Here it is shown that the rod S has been drawn out to half the distanceof the length of the splined end, and as a consequence the plate d hasbeen drawn back until the arc D D through which that end travels hasgrown smaller and does not lift the valve so far. The…
Steam-engines
