Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 18
L … FIG. 4. the arrow A, the exhaust being in the direction of the arrow B at thesame time. In Fig. 5 the head-end steam port is full open at the same time thatthe crank-end exhaust is still full open. The eccentric e is at the endof its travel and the crank c is relatively in the position shown.…
Steam-engines
