Machine design; a manual of practical instruction in designing machinery for specific purposes, including specifications for belts, screws, pins, gears, etc., and many working hints as to operation and care of machines (1918)

Wallace, Ernest L · Chicago, American technical society · leaf 65

An illustration from Machine design; a manual of practical instruction in designing machinery for specific purposes, including specifications for belts, screws, pins, gears, etc., and many working hints as to operation and care of machines, 1918, leaf 65
Fig. 22. Buttress Thread therefore, by the upper nut, which should be the thicker of the two;but for convenience in applying wrenches the position of the nuts isoften reversed. The form of thread adapted to transmitting power is the square … Fig. 23. Modification of Square Thread thread, which, although giving less bursting pressure on the nut, isnot as strong as the V-thread for a given length, since the total sec-

Machine design

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
