Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 184
er are shown with the valve gear removed and the valves andports in cross section, while on the other end the valve cranks have beenleft in place and show their relative position to the valves at the oppositeend. The steam and exhaust wrist plates are shown at A and B, respec-tively, and above A is… … 174 VALVE SETTING E, the exhaust-valve crank hjF; G is, the bell crank and H the knock-offcam. On the other end of the cylinder where the valves and ports arein cross section, the dotted lines E, F, G and H denote the center linesof the same parts on that end, and the arcs at the ends of these…
Steam-engines
