Benjamin, Charles Henry, 1856- [from old catalog], Hoffman, James David, 1868- [from old catalog] joint author · New York, H. Holt and company · leaf 65
is more or less a matter ofchance whether the fracture extends through the flanges. When ribs are used, the tendency is still to shear the webalongside of the rib as in 16 and 18, with a possibility of the breaknot extending through the flanges (see No. 20). It is apparent that thickening the… … DESIGN OF FRAMES 47 The addition of ^-in. fillets increased strength and stiffness,while J-in. fillets were less effective. Although these experiments were not sufficient in number tojustify definite conclusions, it is evident that the web and notthe flanges is the weak part of the ordinary G frame…
Machine design
