Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 19
FIG. 5. Fig. 9 shows the valve having reached the extreme of its travel inthe direction shown, leaving the head-end port wide open for exhaust andthe crank-end port wide open for steam, the piston having advanced toabout 25 per cent, of its return stroke. Fig. 10 shows the valve at the point of…
Steam-engines
