Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 20

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 20 — <- … FIG. 6. Fig. 5 shows the admission line being recorded on the head end and thecounter-pressure line on the crank end. Fig. 6 shows the admission lineon the head end completed up to the point of cut-off, and the counter-pressure line on the crank end still extending. Fig. 7 shows that theexpansion…
