Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 211
FIG. 199. inlet pins B D are inches from the horizontal line, and adjust the valve stems G G until each of the top inlet valves are lapped inches. Next turn the engine over, set the piston at the bottom of the stroke, thewrist plate again being central, adjust the valve stems H H until each of … AIR COMPRESSORS 201 the bottom inlet valves is lapped inches; then lock the valve stems securely. For setting the discharge valves, put the piston at the bottom of thestroke, the wrist plate being central, adjust the connections A and A until C and C are each inches from the horizontal line, and…
Steam-engines
