Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 22

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 22 — ^r … FIG. 8. Fig. 13 the valve travel will equal twice the width of the port, plus thesteam lap, as in Fig. 3. Other Important Considerations Eeferring to Fig. 14, linear advance of an eccentric is the linear dis-tance equaling the lap and lead measured on a like perpendicular to the90-degree radius H…

Steam-engines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
