Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 30
lingvalves in engines already in operation. It will be seen in Fig. 17 thatif the outside lap is increased an amount corresponding to N—M on thescale of the diagram, admission will take place later, at the crank posi-tion 0—A, where the lead will be reduced to I—G, and cut-off will takeplace… … riG. 17.
Steam-engines
