o the point of admissionat K; 0—A is then drawn perpendicular to K—C, and the distance0—M^, which by measurement is found to be f of an inch, is one halfthe steam lap that would be required to bring cut-off at half stroke. Withthis condition, the angle of advance will be A—0—C, which by… … 26 VALVE SETTING to open the port wide for exhaust, when the exhaust is a maximum, andwith a connecting rod considered of infinite length it is to cut off atthree fourths of the stroke. The exhaust port is to begin opening when thepiston is at one eighth of its stroke from the end and admission…
