Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 44
FIG. 29. FIG. 30. valve-circle diameter intersects the crank circle, cuts the line of dead cen-ters at a point N distant from the center 0 by an amount equal to thelap plus the lead of the valve. To prove that the line joining the pointsof admission and cut-off is tangent to the steam-lap circle,…
Steam-engines
