Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 47
er. It will be noted that the different points of information given by thediagram appertain part to the steam side and the others to the exhaustside of the valve, while the angle of advance and the valve travel arecommon to both sides. In order to construct a complete diagram, it isnecessary that… … A STUDY OF THE ZEUNER SLIDE-VALVE DIAGRAM 37 or two of the points given must belong to a different side of the diagramfrom the others, and one of the points must be a linear measurement, suchas the steam lap, steam lead, or maximum opening; otherwise, as canreadily be seen, the angular measurements…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
