Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 805
er for fastening the head. 51 S02 GEERING. G, dial or index, having rows of holes of different numbers drilled on its face, which can be dividedby means of the point and spring I, so as to cut any number of teeth wanted. K is a hand lever for raising spindle F and dial with the geer while cutting.… … L is a balance lever weight to counterbalance the spindle and dial, and the weight of the geerwhich is being cut. The weight has a movable cover for the purpose of putting in more or less weight,as the heft of the geer being cut may require. To the extreme left of the upper part of the frame, Fig.…
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
