whole makes a complete removablestructure, separate from the cylinder, which can be disconnected from theeccentrics and removed from the cylinder in a few minutes for inspection,repair, or permanent replacement. The arrangement of the valves below the cylinder is the Wheelock sys-tem. The… … 64 VALVE SETTING the cylinder it is relieved by the raising of the inlet or steam valve fromits seat. General Arrangement of Valve Gear The general arrangement of the valve gear, eccentrics, etc., can be seenby reference to Fig. 61, which is the high-pressure side of a cross-com-pound engine. The…
