Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 75
FIG. 62. FIG. 63. secured in place by screws. The eccentrics C and D are the steam eccen-trics and B and E the exhaust. They are attached to the valve mechanismby their respective rods. The throttle of the engine at F admits steamto the steam chest under the cylinder and equally to the valve plugs…
Steam-engines
