Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 77
and seats is shown. Theoutlet valve is actuated by the eccentric acting on the toggle joint li, con-nected between the two pairs of links, from the point i. where it is fixed,and the point /, where the link is fastened to the valve-rod head h on theoutlet valve stem. 66 VALVE SETTING Position of… … FIG. 65. For the sake of simplicitj-, each valve, i.e., outlet and inlet, is shownwith its gear separate for the moment, eliminating one while the other isunder consideration. The cross section of the valve and seat is not in THE GREENE-WHEELOCK ENGINE 67 proper relative position, but so placed in…
Steam-engines
