Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 80

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 80 — t (exhaust) valve and plug with the valve gearassembled. This first view shows the valve wide open to ports on the out-side end of its movement. It will be noted that the eccentric is on thebottom center of its travel and the toggle stub end a is at the lowest pointit reaches below the line C C,… … 70 VALVE SETTING toggle stub end has come up toward the line C C; the point h has reacheda position corresponding to the near edge of the ports and the valve hasjust cut off or closed for compression. In Fig. 70 the eccentric has reached the point E on its travel, and thetoggle links now forming a…

Steam-engines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
