Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 96

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 96 — the shaft, as is more common in shaft governors. It thusgoverns by varying the angular advance of the eccentric in place of chang-ing the travel of the valve. The arrangement is such that when cut-offtakes place the cut-off valve is moving in an opposite direction to themain steam valve, giving a…

Steam-engines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
