Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 98
re driven by the governor eccentric, thus equalizingthe Avork on the various cylinders. The main rock shafts Jf and A are carried on brackets from the lowerpart of the cylinder, and the short upper pins or shafts m and a are car-ried by similar brackets at the upper corners of the cylinder.… … EXHAUST VALVE ^///////////////////////////////A y/////////////////////////////^7^7^ FIG. 88. §8 VALVE SETTING crossheads c c, Fig. 86, are arranged to wipe over and all valve stems areadjustable. The valve seats or grids are separate from the cylinder and are putin place with scraped joints,…
Steam-engines
