th anafter-grinding, cutting away four-tenths of the cylinder, as shownat I, Fig. 143. Here the line m represents the locking face of thejewel and the line o the clearance to free the escaping tooth, theangle at n being about fifty-four degrees. This angle (n) shouldleave the rounding of the stone…
Clocks and watches
