ler watches it frequently runsup as high as twenty-five. Although the cylinder is seemingly avery simple escapement, it is really a very abstruce one to followout so as to become familiar with all of its actions. THE CYLINDER PROPER CONSIDERED. We will now proceed and consider the cylinder proper,… … Fig. 131 We have here also repeated the line f of Fig. 130 as it cuts thecylinder in half, that is, divides it into two segments of 180 degreeseach. If we conceive of a cylinder in which just one-half is cutaway, that is, the lips are bounded by straight radial lines, we canalso conceive of the…
