The watchmakers' lathe, its use and abuse; a story of the lathe in its various forms, past and present, its construction and proper uses (1903)

Goodrich, Ward L. [from old catalog] · Chicago, Hazlitt & Walker · leaf 168

An illustration from The watchmakers' lathe, its use and abuse; a story of the lathe in its various forms, past and present, its construction and proper uses, 1903, leaf 168 — he index of the lathe-head, which should havebeen previously inserted, so as to hold the spindle fromrotating and revolve the drill half way round by turning thelathe spindle. After fastening it with the index pin, proceedto grind the opposite edge, and if the drill has been properlyset in the… … —A

Clocks and watches · Lathes

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
