The watchmakers' lathe, its use and abuse; a story of the lathe in its various forms, past and present, its construction and proper uses (1903)

Goodrich, Ward L. [from old catalog] · Chicago, Hazlitt & Walker · leaf 182

An illustration from The watchmakers' lathe, its use and abuse; a story of the lathe in its various forms, past and present, its construction and proper uses, 1903, leaf 182 — imately.The reason why we cannot get the exact length of staff isthat the setting of the jewel hole is sometimes lefthigher than the jewel, or that of the end stone may havebeen left the same wTay instead of being just flush, but ifwe notice how the jewels are set an allowance can be madewhich will… … Fig. 146. screw it would be very easy to bend a pivot with it, and ofthe two forms it is perhaps more accurate and besides costsmuch less. The advantage of the Grossman gauge is thatthe jaws are actuated by a spring which always gives auniform tension on the work and can be handled quicker.Could we…

Clocks and watches · Lathes

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
