The watchmakers' lathe, its use and abuse; a story of the lathe in its various forms, past and present, its construction and proper uses (1903)

Goodrich, Ward L. [from old catalog] · Chicago, Hazlitt & Walker · leaf 212

An illustration from The watchmakers' lathe, its use and abuse; a story of the lathe in its various forms, past and present, its construction and proper uses, 1903, leaf 212 — shown in Fig. 165. This hardened steelwire cutter is held in a tool holder, as shown, and the toolholder is bolted firmly in the tool post of the slide rest, withall slides set square to the line of centers of the lathe. Hav-ing previously turned the cutter smooth on both sides, boredand relieved…

Clocks and watches · Lathes

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
