The watchmakers' lathe, its use and abuse; a story of the lathe in its various forms, past and present, its construction and proper uses (1903)

Goodrich, Ward L. [from old catalog] · Chicago, Hazlitt & Walker · leaf 222

An illustration from The watchmakers' lathe, its use and abuse; a story of the lathe in its various forms, past and present, its construction and proper uses, 1903, leaf 222 — ts are needed. Index plates of the numbers needed for the average watchor clock may be purchased cheaply of any material dealer;if not ordered at the time the wheel cutter is purchased, the THE AMERICAN LATHE. 221 size and make of lathe on which they are to be used shouldalways be given. These… … Fig. 199. Quill to go in Rivett sliderest, with index, latch and draw-inspindle for wheel cutting. Fig. 200. Graduated and adjustableknee to hold Slide Rest vertical forwheel cutting.

Clocks and watches · Lathes
