United States. Patent Office · Washington, D.C., Govt. Print. Off. · leaf 841
or the purpose specified. 20. In a magazine-phonograph, the com-bination of a magazine-wheel; a pivotally-supported shaft; a driving-wheel for saidmagazine-wheel on said shaft ; a pivot ally- 85supported link on said shaft; and a bowedspring arranged between said wheel and link,for the purpose… … Fj^r.
Phonograph · Patents
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Graphophone patents], 1878, leaf 841](https://img.insideoutlibrary.com/img/1024/ia-graphophonepaten07unit-841-543.webp)
