s geared back from thecrank shaft to a separate pulley shaft by means of a spur pinion, and thereare driving gears at both ends of the loom. This change re-enforces thedriving mechanism and qualifies it for the heavier work demanded inweaving heavy belting for which this loom is specially designed.… … HEAVY DUCK LOOM [65] CROMPTON y KNOWLES LOOM WORKS Extra Heavy Duck Loom THE transition from the Heavy Duck Loom to the Extra Heavyintroduces several important differences in construction. Theframe is very much heavier, having high arched sides with two iron crossgirts at the top, an iron lower…
