in position to receive the shuttle as it leaves the box;also if the boxes were changed at the same time as the harness,considerable trouble would be experienced in running theshuttle, which would cause it to chip. 84 WEAVING PLAIN AND FANCY. FILLING STOP MOTION. Fl^X- 21 illustrates the stop motion… … Fig 21. directly under the back end of tilling motion dagger, B. Thebottom end of the rod is attached by a stud to a slotted bracketat C. This rod is threaded at the bottom and can be raised orlowered. A small connection D connects the filling motion,dagger B, to cam on stud that carries the…
Weaving
