Weaving; a practical guide to the mechanical construction, operation, and care of weaving machinery, and all details of the mechanical processes involved in weaving (1909)

American School of Correspondence, Nelson, H. William (Hector William), b. 1869 · Chicago, American School of Correspondence · leaf 19

An illustration from Weaving; a practical guide to the mechanical construction, operation, and care of weaving machinery, and all details of the mechanical processes involved in weaving, 1909, leaf 19
Fie. 5. Fig. 7. Fig. 5 shows the mangle of a straight-built bobbin, but asstiated before, this motion is not of as great value as the ellipticmangle gear, on account of the greater production of the latter. Bobbin Holder. The yai-n is received from the spinningframe on a bobbin or pirn; it is then…
