Weaving; a practical guide to the mechanical construction, operation, and care of weaving machinery, and all details of the mechanical processes involved in weaving (1909)

American School of Correspondence, Nelson, H. William (Hector William), b. 1869 · Chicago, American School of Correspondence · leaf 325

An illustration from Weaving; a practical guide to the mechanical construction, operation, and care of weaving machinery, and all details of the mechanical processes involved in weaving, 1909, leaf 325
Fig. 1.5. Showing Overhead Lever Lift and Independent Batten Motion. and causing niisspicks. In the second instance, if the cylinderpresses too hard against the needle board, the lacing is often cut,and the needles have a tendency to pierce the card where it isblank. 293 JACQUARD MACHINES 15 Having…
